Technical Specifications
| Frequency Response | 70 Hz – 16 kHz (±3 dB), 60 Hz – 18 kHz (±10 dB) |
| Nominal Coverage (-6dB) | 100° (H), 10° (V) |
| Sensitivity (@1w/1m) | HF/LF: 112 dB SPL / 100 dB SPL |
| Power Rating (AES) | HF/LF: 80W/400W (AES) |
| Nominal Impedance | 16 ohm |
| Maximum SPL | HF: 137 dB SPL peak |
| Drivers | 1×12″ woofer (75mm voice coil), 1×3″ compression driver (75mm voice coil) |
